Oil water separator costs in Canada range from $800 for a basic surface-mount unit to $60,000+ for a fully installed underground system — unit price, installation, and ongoing maintenance all vary significantly depending on your facility type and province. If you're building a capital budget or comparing quotes, this breakdown gives you the real numbers.
For broader context on how these systems work and which type fits your application, start with the complete oil water separator guide before finalizing your budget. This article focuses strictly on cost.
What Does an Oil Water Separator Unit Cost in Canada?
Unit cost is driven almost entirely by flow rate capacity. A 0.5 GPM coalescing unit sized for a single wash bay costs a fraction of what a 50 GPM system for a commercial car wash requires. The table below reflects current Canadian market pricing for OlioSep™ separators and comparable units as of 2026.
| Unit Type | Capacity | Unit Cost (CAD) |
|---|---|---|
| Surface mount | 0.5–2 GPM | $800–$2,500 |
| Surface mount | 4–8 GPM | $2,500–$6,000 |
| Surface mount | 16–30 GPM | $6,000–$15,000 |
| Surface mount | 50 GPM | $12,000–$20,000 |
| Underground tank | 30–100 GPM+ | $8,000–$40,000 |
Surface-mount units are self-contained, typically polypropylene or coated steel, and are designed for installation above the finished floor. Underground tanks are precast concrete or fiberglass, require excavation, and are priced before any site work is included.
What Does Installation Add to the Oil Water Separator Price?
Installation cost is where budgets often get surprised. A surface-mount unit in an existing shop with accessible floor drains can be connected in a day. An underground tank in a new construction vehicle wash facility is a multi-week civil project involving excavation, concrete, and backfill.
| Installation Type | Typical Cost (CAD) |
|---|---|
| Surface mount (simple, existing drain) | $500–$1,500 |
| Flush mount (in-floor, cut and patch) | $1,500–$4,000 |
| Underground (excavation + concrete work) | $5,000–$20,000 |
Labour rates vary by province. In Ontario and British Columbia, licensed plumbers typically bill $95–$135/hour. Quebec rates for unionized tradespeople run $85–$120/hour. Alberta and the Prairie provinces tend to fall between those ranges, though industrial site work in remote locations can push day rates significantly higher.
Total Installed Cost: What to Budget by Scenario
These figures combine unit cost and installation to give you a single planning number. They assume standard site conditions, no unusual plumbing complications, and local labour at provincial average rates.
| Scenario | Total Installed (CAD) |
|---|---|
| 1–2 bay shop, surface mount 2 GPM | $1,100–$4,000 |
| 3–4 bay shop, surface mount 8 GPM | $3,000–$7,500 |
| 5–6 bay shop, surface mount 16 GPM | $7,000–$18,000 |
| Commercial car wash, underground 50 GPM | $13,000–$60,000 |
The wide ranges reflect real variability: an existing shop with properly stubbed drains and a short pipe run lands at the low end. A new-build facility with no drain infrastructure, freeze protection requirements, and a municipal permit process lands at the high end.
If your scenario sits near the top of a range, budget to the high end. Cost overruns on plumbing and civil work are common, not exceptional.
What Drives Oil Water Separator Cost Up or Down?
Flow Rate and Unit Sizing
Flow rate is the primary cost driver for the unit itself. A 2 GPM unit handles one or two bays washing light vehicles. Jump to 16 GPM for a busy fleet shop or a facility running hot-water pressure washers on heavy equipment. Oversizing doesn't hurt performance, but it does inflate capital cost unnecessarily. Undersizing causes regulatory problems. Getting the sizing right before you buy is worth the time.
Above Ground vs. Underground Installation
This single decision can add $5,000–$20,000 to your total project cost. Underground systems require excavation, a crane or forklift for tank placement, concrete collar work, and a longer permitting timeline. Above-ground units go in faster and cost less to install, but they're not appropriate for every facility type or municipal requirement. A detailed comparison is in the above ground vs. underground oil water separators article.
Existing Plumbing vs. New Construction
Retrofitting a separator into an existing building usually costs less than new construction — the drain infrastructure is already there. New construction gives you the opportunity to rough in the separator at the framing stage, which reduces long-term installation cost even if total project cost is higher.
Province and Local Labour Rates
A surface-mount installation that costs $800 in labour in Regina might cost $1,400 in Vancouver. For underground work, the gap is wider. Build your estimate using local quotes, not national averages.
Freeze Protection Requirements
Facilities in northern Ontario, Quebec, Manitoba, and most of the Prairies need to account for freeze protection. Outdoor installations or units in unheated bays may require insulated housings, heat trace, or relocation of the unit to a heated mechanical room. This adds $500–$3,000 to the project depending on the solution.
Cost vs. Compliance Fine: The Real Comparison
The most common objection to OWS investment is cost. The second most common outcome of skipping it is a fine that costs more than the system would have.
Non-compliant discharge into municipal sewer systems in Ontario can result in fines of $500 to $10,000 per day under the Ontario Water Resources Act and municipal sewer use bylaws. Many municipalities have zero-tolerance enforcement for hydrocarbon discharge, particularly after a spill event draws attention to a facility.
The federal Fisheries Act carries separate penalties. A single charge for depositing a deleterious substance in fish-bearing waters can result in fines exceeding $1,000,000 for a corporation under the amended Act (Fisheries Act, R.S.C. 1985, c. F-14, as amended by Bill C-68). Even a minor infraction involving a small shop can produce a fine that exceeds the cost of 10 properly installed OWS units.
The regulatory math is straightforward: a $4,000 installed system is not a capital expense to minimize. It's insurance with a very low premium relative to the liability it eliminates.
Annual Maintenance: The Ongoing Budget Item
Maintenance cost is not one-time. Budget for it annually as part of your facility operating cost.
Annual oil water separator maintenance includes oil/water emulsion pumping and disposal, coalescing media inspection and replacement, and periodic inspection by a licensed contractor to confirm discharge compliance. In some provinces, maintenance records must be kept on-site for municipal inspection.
Typical annual maintenance costs:
- Small shop (1–4 bays, low wash volume): $300–$700/year
- Mid-size facility (5–10 bays, moderate vehicle washing): $700–$1,500/year
- High-volume commercial (car wash, fleet yard, heavy equipment): $1,500–$2,000+/year
Waste oil disposal is charged by volume and varies by region. Facilities in remote areas pay more for pickup. If your OWS is capturing significant oil volume, ask your maintenance contractor about waste oil recovery credits — in some markets, high-grade recovered oil has resale value that partially offsets disposal cost.
How to Get an Accurate Oil Water Separator Quote
Getting a useful quote requires specific inputs. A vendor who quotes without asking these questions is guessing.
Have the following ready before contacting a supplier:
- Bay count and wash activity — How many bays wash vehicles? What type: light passenger vehicles, heavy trucks, equipment with hydraulic oil?
- Province and municipality — Discharge standards vary. Some municipalities have stricter limits than provincial minimums.
- Discharge point — Municipal sewer, on-site holding tank, or land discharge?
- Existing drain layout — Do floor drains already run to a single collection point?
- Installation preference — Surface mount, in-floor flush, or underground?
With these five inputs, a competent supplier can quote you a unit and a realistic installation range within 24–48 hours.
Need help with oil water separators?
ERE Inc. has been Canada's environmental equipment specialist for 30+ years.
→ Request a Quote | 1-888-287-EREC | Browse Oil Water Separators | sales@ereinc.com
Frequently Asked Questions
How much does a basic oil water separator cost in Canada?
A basic surface-mount oil water separator for a 1–2 bay shop costs $800–$2,500 CAD for the unit, plus $500–$1,500 for installation. Total installed cost typically runs $1,100–$4,000 depending on your province and existing drain infrastructure.
Why does underground installation cost so much more than surface mount?
Underground installation requires excavation, concrete collar work, and crane or equipment rental for tank placement. The civil and concrete work alone typically runs $3,000–$10,000 before any plumbing connections. Surface-mount units avoid all of that and can be installed in a day by a licensed plumber.
Is oil water separator installation covered by insurance?
Installation itself is not typically covered by commercial property insurance. However, some insurers offer premium reductions for facilities that can demonstrate active stormwater and effluent management. Check with your broker before assuming coverage either way.
How much does it cost to maintain an oil water separator per year?
Annual maintenance for a Canadian facility runs $300–$2,000/year depending on size and discharge volume. Small shops with low wash activity land at the low end. High-volume commercial car washes or fleet yards with heavy oil accumulation land at the high end.
Can I lease or rent an oil water separator instead of buying?
Some suppliers offer lease or rent-to-own arrangements, particularly for underground systems where the capital cost is highest. Monthly payments for a mid-size leased system generally run $150–$600/month CAD. Ask your supplier directly — availability varies and not all configurations qualify for lease programs.
