The TI3M is a 316 stainless steel insertion paddle wheel flow meter for pipes from 1/2 in to 24 in. It shows flow rate and total on a dual LED display and gives pulse and 4-20mA outputs. It installs through a tee, saddle or weld-on fitting.
- Dual LED display
- Pulse, 4-20mA and RS485 outputs
- 316 stainless steel body
- Accuracy of ±0.5% of full scale
- Fits 1/2 in to 24 in pipe with TI3 Series fittings
- Lifetime warranty on the paddle wheel assembly
Install with a TI3 Series tee or weld-on fitting (sold separately). EPDM (+$49) or FFKM (+$399) seals are available. Contact us to order.
