Features
• Absolute-Rated Beta 5000 (99.98%) retention efficiency
• 7.0 square feet (0.65 m2) of media surface area per 10" length
- Maximum throughput and particle retention
- Longer service life reduces maintenance costs
• 100% polypropylene construction offers wide range of chemical compatibility
• Rigid, molded cage provides greater structural integrity
• Gradient, fixed pore structure increases dirt-holding capacity and resists unloading under high differential pressure
• Manufactured in state-of-the-art white room for high purity
• Complies with Food & Drug Administration's CFR criteria for food & beverage contact
• Meets USP Class VI Biological Test for plastics
• Various end cap configurations available to fit existing housings
• Produced in continuous lengths up to 40 inches
• Optional pre-flushed cartridges available for electronic and pharmaceutical applications
Applications
• RO Prefilters
• Process Water
• Plating Solutions
• Chemicals
• Water & Wastewater
• Food & Beverage
• Bottled Water
• Microelectronics
• Paint/Inks
• Cosmetics
Ordering Guide (Example: MPX1.0-10S3E)
| MPX | |||||
| Product Code | Micron | Length | End Cap Configuration | Gasket/O-Ring | Option |
| MPX | 0.2 0.45 1.0 3.0 5.0 10.0 20.0 30.0 40.0 50.0 | 9.75" 10" 20" 30" 40" | S1 = DOE S3 = 222 w/ Fin End S4 = 222 w/ Flat End S5 = 226 w/ Fin End S6 = 226 w/ Flat End S7 = Internal O-ring with Recessed Plug S9 = Internal O-ring on both ends | B = Buna N E = EPDM S = Silicone V = Viton T = Teflon encapsulated Viton (O-ring | F = Flushed with 18megohm DI water (Constructed with 10" modules) |
