The 100 Series is a submersible level sensor that sits at the bottom of a tank and measures the head pressure of the liquid. It has no moving parts, an integrally molded weight, a PTFE Teflon jacketed cable and FFKM Kalrez O-rings, and is offered in PVC, PP, PVDF, PTFE or 316 SS housings.
- Housings in PVC, PP, PVDF, PTFE or 316 SS
- Ceramic sensing diaphragm, accuracy of ±0.5%
- Integral molded weight, no floating
- PTFE Teflon jacketed cable and FFKM Kalrez O-rings
- 4-20mA output (HART, ratiometric, voltage and RS485 options)
- Standard 0-34 ft range, other ranges available
Priced as shown for the 0-34 ft range with 11 m cable and 4-20mA output. Other ranges (14, 20, 54 ft), cable lengths (5, 15, 20 m), outputs, RS485 (+$250), HART (+$200) and temperature reading (+$200) are available. Contact us to order.
