The TKW is an in-line paddle wheel flow meter for corrosive and non-corrosive liquids, offered with PVC, PP or PVDF bodies. It is a blind unit with a bright LED flow indicator and gives a pulse output, with voltage or 4-20mA outputs available as options. True-union ends are used up to 2 in and flanged ends at 3 in and 4 in.
- True-union design with M12 quick-connect cable and 360 degree rotatable housing
- Accuracy of ±0.5% of full scale
- Pulse output with optional 4-20mA, 0-5V or 4-20mA + pulse outputs
- Pre-programmed with no setup, LED flow indicator
- PVC, PP or PVDF bodies, 1/2 in to 4 in
- Lifetime warranty on the paddle wheel assembly
Optional 4-20mA (+$149), 0-5V (+$249) or 4-20mA + pulse (+$249) output, EPDM (+$49) or FFKM (+$399) seals and alternate end connections are available. Contact us to order.
