1 / 4
Features
• Lighweight and easy installation.
• Wall-hanging installation makes for space-saving.
• O-ring design improves sealing and prevents loosening
• Clamp type clousure for fast installation and easy filter cartridge change-outs without any tools.
• Acid washed
• Electropolished
Applications
• Chemicals
• Petrochemical
• Beverage
• Food
• Electroplating
• High temperature manufacturing processes
• RO Pre-filtration process
• Water filtration
• Pharmaceutical
• Sewage treament
• Electronic
• Etc...
| Model | A m/m | B m/m | C m/m | D m/m | E m/m | GPM | Weight |
| ERS-1-1H | Ø106 | 395 | 97 | 50 | 165 | 5 | 9 lbs |
| ERS-1-2H | Ø106 | 645 | 97 | 50 | 165 | 10 | 12 lbs |
| ERS-1-3H | Ø106 | 845 | 97 | 50 | 165 | 15 | 16 lbs |
| Part Number | Length | End Cap | Cartridge Size | In/Out | Max Pressure | Material Steel |
| ERS-1-1H-SS304-3/4FPT | 10" | DOE | 2.3"-2.7" x 10" | ¾" FNPT | 150 PSI | 304 Stainless |
| ERS-1-2H-SS304-3/4FPT | 20" | DOE | 2.3"-2.7" x 20" | ¾" FNPT | 150 PSI | 304 Stainless |
| ERS-1-3H-SS304-3/4FPT | 30" | DOE | 2.3"-2.7" x 30" | ¾" FNPT | 150 PSI | 304 Stainless |
