ERS-1080-BB-SS304-6F-REN
Sampson 6 Bag Filter Housing: Rental
Bags: 6 | Bag Size: No.2 (7 x 32 in) | Max Pressure: 140 psi
Price on quote · 4 business hours
Browse Categories
Water & Liquid Filtration & Treatment
Browse Water & Liquid Filtration & Treatment
Related in Water & Liquid Filtration & Treatment
- Filter Bags
- Cartridges
- Cartridge Housing
- Oil/Water Separators
- UV Systems for Commercial
- UV Systems for Residential
Department
Bag Filter Housings
Bag filter housings for industrial liquid filtration: Sampson uPVC and 304/316 stainless steel housings made in Canada, multi-bag housings from 540 to 1,080 GPM, plus Shelco BFS and A.P. Buck BF series. Send your flow rate and fluid for a sizing quote.
7 products
ERS-PL-004B
Sampson Filter Housing Replacement Parts: O-Rings, Baskets, Eyebolt Kits, Legs and Spacers
Parts: 12 options | O-Ring Materials: Buna or EPDM
Price on quote · 4 business hours
ERS-90-SE-PL
Sampson™ Bag Filter Housings
2'' flange or 2.5" FNPT Inlet/Outlet | Design Pressure: 100 psi | Maximum Temperature: 45°C | No.1 size, 7" x 17" bags
Price on quote · 4 business hours
BFS SERIES
BFS Series Multi-Bag Housings
2 to 6 bags (#2 size) | 304L or 316L stainless steel | 150 psig @ 250°F clamp / 300°F swing bolt | 3 to 6 in RF flanges | Flow 350 to 1,050 GPM
Price on quote · 4 business hours
ERS-540-BB-SS304-4F
Sampson™ Multi-Bag Filter Housing
4" Flange Bottom Inlet/Outlet | Maximum Operating Pressure 100 PSI | (3) No.2 size, 7" x 32 " bags | Exterior Finish: Electrolyzed
Price on quote · 4 business hours
ERS-90-SE-SS304-2FPT
Sampson™ High Pressure Bag Filter Housings
2" FNPT Inlet/Outlet | Operating Pressure: 150 PSI | Design Pressure: 225 PSI | Operating Temperature: 75 °C | No.1 size, 7" x 17 " bags
Price on quote · 4 business hours
A bag filter housing holds one or more filter bags in a pressure vessel and removes solids from process water, wastewater and other liquids. ERE manufactures the Sampson line in Canada: uPVC housings for corrosive liquids (90 or 180 GPM, 45°C maximum), 304/316 stainless steel high-pressure housings (90 or 180 GPM) and multi-bag housings that hold 3, 4 or 6 #2 bags for 540 to 1,080 GPM. For other configurations, ERE also carries Shelco BFS Series multi-bag housings (2 to 6 bags) and A.P. Buck BF Series housings for #1 to #4 bags in stainless or carbon steel.
Sampson uPVC and multi-bag housings accept filter bags of every micron rating and material. Send us your flow rate, fluid and temperature, and we will size the housing.
Bag filter housing FAQ
Single-bag or multi-bag housing?
Size the housing to your flow. A single bag handles moderate flows: Sampson single-bag housings are rated 90 GPM with a #1 bag and 180 GPM with a #2 bag. Above that, a multi-bag housing spreads the flow over several bags, which also lengthens the time between change-outs. Our guide compares single-bag, multi-bag and duplex housings.
Stainless steel or uPVC?
uPVC housings resist corrosion, are light and easy to install, and suit corrosive liquids at moderate temperatures (Sampson uPVC: 45°C maximum). Stainless steel handles higher temperatures and pressures; 316 resists chlorides better than 304, and sanitary finishes are available for food and pharmaceutical use. Check chemical compatibility before you choose; see our uPVC vs stainless steel guide.
Which bag sizes fit which housings?
Industrial filter bags come in four standard sizes: #1 (7" x 17"), #2 (7" x 32"), #3 (4" x 8") and #4 (4" x 15"). Sampson single-bag housings take #1 or #2 bags and Sampson multi-bag housings take #2 bags; A.P. Buck BF Series housings cover all four sizes. Our filter bag size guide covers rings and compatibility.
How do I know when to change the bags?
Watch the pressure drop across the housing. Sampson housings have 1/4" gauge ports on the cover, and pressure gauges are listed as accessories for the high-pressure model; change the bag when the differential pressure reaches the limit set by the bag manufacturer or your procedure.
