All soil and sediment equipment in one place — sampling tools, monitoring instruments, and treatment systems for soil, sludge, and sediment work.
300 / 500 / 1000 L tanks (CMP03 / CMP05 / CMP10) | AISI 304 stainless steel metal parts | Plunger metering pump, manual flow adjustment 10–100% | Polyethylene tank with visual level gauge | For small WWTPs, pairs with TEKNOBAG®-DRAIMAD®
Emulsion-base polyelectrolyte | Max 2,000 or 6,000 L/h solution | AISI 304 stainless steel | Automatic, digital controller | Min. 20 min ageing
Automatic continuous powder polyelectrolyte preparation | 750–6,000 L/h solution output (4 models: CAP07CE–CAP60CE) | AISI 304 stainless steel construction | 3-stage process: dilution, dispersion, ageing/storage tanks
Thickens 0.5–3% DS sludge to 5–15% DS | Capacity up to 200 m³/h per unit | Capture rate up to 98% | Archimedean-screw rotating drum | Plug-and-play with control panel + washing pump
Microfiltration down to 20 µm | Filter cloths 20/30/40/60/80/100 µm | Gravity-fed continuous filtration, minimal head loss | ABS supports + polyester cloth (full AISI 304 option) | 90% less reject water, no external wash water
AISI 304 stainless steel | Belt widths 600–2000 mm | Flow 1–140 m³/h | Cake dry solids 18–30% | Solids capture up to 98%
2–12 bag models (manual or pressurized) | AISI 304 stainless steel frame | 15–30% dry solids after a few hours | 50–95% DS after ~2 months bag storage | Treats 2–20 m³ sludge/day @ 1% DS
Dewatering Bag Size: 3' x 4' | Raw Material: PP | Color: Black | Micron: 50
Infrared LED optical probe | 10 m (33 ft) marked cable | 6x AA alkaline, ~1 yr battery life | 2.2 kg (5 lb) | -20 °C to 50 °C operating
• Three 4 ft. extensions | • Deluxe carrying case
Stainless steel construction | 2-1/4" & 3-1/4" diameters | 8"–12" lengths | 5/8" threaded connection | One-way valved core & auger tips
Stainless steel | 1-1/4" dia x 24" length | 5/8" thread connection | Heat-treated replaceable core tip | Accepts 1" core catcher + 1" x 24" plastic liner
1-1/4 in (3.2 cm) OD tubing | 15 ft overall — three 5 ft sections | 177 mL/ft (6 oz/ft) capacity | For settleable solids 5% or less | 1 ft graduation markers
Polycarbonate w/ UV stabilizer | 3/4 in (1.9 cm) OD tube, blue 1-ft markings | 3 x 5 ft sections (15 ft total) | Withstands heat to 280°F (138°C) | For ≤5% settleable solids
Electrolyte solution for soil/solid sample pH prep | Soil ratios 1:1, 1:2, 1:5 | Sizes: 30 mL, 230 mL, 500 mL | 5-yr shelf life (unopened) | Reagent-grade, tamper-sealed
pH range -2.00 to 16.00 pH | Accuracy ±0.02 pH | Resolution 0.01 pH | Temp range -5.0 to 105.0 °C | 3x 1.5V AAA, ~1400 h battery life
Transfer Pump: 10 GPM | Main Vacuum Gauge: 0–60" H2O | Inlet/Outlet: 8" / 6" | Control: NEMA 4, CSA approved
0–100°C range (C43 scale) | ±1% full-scale accuracy | 3/8" SS stem with 1/4" fast-response tip | 3" hermetically sealed dial | Stem lengths 2–6 ft (24"–72")
Compressor: Oilless rotary vane | Motor: 3 HP, 115/230 V | Open Flow: 25 CFM | Max Pressure: 15 PSI
