Features
• Heavy duty carbon steel 304L or 316L Stainless Steel Construction for maximum durability
• Optional 134 epoxy coating for seawater or corrosive applications
• Swing bolt closure and dait assembly for easy operation and maintenance
• Available in 2”, 3”, 4”, and 6” connection sizes
Applications
• Water
• Chemicals
• Food & Beverage
• Electronics
• Inks / Paints / Coatings
• Coolants
• Pulp & Paper
Specifications & Operating Parameters
| Maximum Operating Pressure | 150 psig (10.3 bar) @ 300˚F (149˚C) |
| Connections | Inlet /Outlet: - 2" Flanges (USB) - 3" Flanges (2USB) - 4" Flanges (3USB, 4USB) - 6" Flanges (5USB, 6USB) Drain Port: - 1/2" FNPT (USB) - 3/4" FNPT (2USB-6USB) Vent Port: 1/2" FNPT Gauge Ports: 1/4" FNPT |
| Gaskets | Buna N Optional: EPR, Silicone, Teflon Encapsulated Silicone, Viton |
| Finish | Glass Bead Optional: electro-polish, passivate or 134 epoxy coating |
| Materials of Construction | Head / Shell: Carbon Steel, 304L or 316L Stainless Steel Eye Nuts and Davit Handle: Zinc Plated Steel Mounting Legs: Carbon Steel or 304L Stainless Steel |
| Baskets | 1/8" perforated Stainless Steel Optional: Various perforation and mesh sizes |
