How the Dulex™ Multiphase Extraction System Works
The Dulex™ system applies high vacuum to a single well to simultaneously extract hydrocarbon contaminants (LNAPL), groundwater, and volatile organic compounds (VOCs). Extracting groundwater creates a cone of depression that influences and contains migrating hydrocarbons toward the extraction well. Recovered fluids pass through the Tornado™ knockout tank and OlioSep™ oil/water separator, while water is polished through UltraSorber™ water treatment media and the air stream is treated through the UltraSorber™ air effluent treatment unit.
Key Specifications
| Part Number | Motor | Max. Flow Rate |
|---|---|---|
| ER-D3-100 | 3 HP, 220 V / 1 ph, XP | 70.6 cfm |
| ER-D5-150 | 5 HP, 220 V / 3 ph, XP | 106 cfm |
| ER-D7-5-300 | 7 HP, 220 V / 3 ph, XP | 212 cfm |
| ER-D10-400 | 10 HP, 220 V / 3 ph, XP | 272 cfm |
| ER-D15-500 | 15 HP, 460/575 V / 3 ph, XP | 353 cfm |
For complete model information, view PDF brochure.
System Includes
- High-vac pump with TEFC motor
- Control panel (NEMA 4)
- Variable speed control for high-vac pump flow
- Multiport manifold
- Tornado™ knockout tank
- Tornado™ knockout tank transfer PD pump with TEFC motor
- Sampson™ bag filter housing with pressure switch
- OlioSep™ oil/water separator
- OlioSep™ internal level switches for transfer pump
- OlioSep™ transfer pump (TEFC)
- UltraSorber™ water treatment media
- UltraSorber™ air effluent treatment unit
- Pressure switch
- Water totalizer meter
- Sampling ports for water and air
- Skid mounted
Applications
- Hydrocarbon contaminant (LNAPL) extraction
- Groundwater extraction and hydraulic containment
- Volatile organic compound (VOC) recovery
