Designed for clarifiers, open-top tanks, and pipelines, this meter is unaffected by fluid color or particulates, ensuring reliable results even in thick concentrations. By monitoring solids concentration, the system helps calculate mass flow and optimize polymer dosing, thickener operation, and pump control, reducing both material and energy costs.
The instrument is available with either a non-intrusive inline sensor or a throw-in probe, featuring easy push-button calibration, automatic damping, and self-diagnostics.
Features
• Real-time readings of silt, sludge, and slurry concentrations
• Ultrasonic, non-nuclear technology (no permits required)
• Monitor Total Suspended Solids (TSS) even in thick concentrations
• Continuously measure, monitor & control the percentage of suspended solids.
• Automate pumps to maintain preferred density
• Easy set-up & push-button calibration
• Simple high & low set-point adjustment
• Automatic dynamic damping
• Advanced self-diagnostics
Applications
• Primary, secondary, and return-activated sludge
• Drinking water plant sludge
• Hydroxide and metal finishing sludges
• Manure for methane gas generation of electricity
• Clay, silica, and lime slurries
• Lime slurries for softening water in drinking water plants
• Resins
• Backwash sludge from sand or membrane filters
• Nano & micro particles
| Part Number | Description |
| MSE-502-IL | Flanged steel spool piece pickup head, overall length 458mm (18 inches). Flange type, pipe diameter and material to suit pipeline |
| MSE-502-TP | PVC probe cage head with stainless steel trim, 150 mm (6 in.) offset from vertical mast. 1 inch Sch. 80 pipe mast x 4 metres (12 feet) long supplied with two stainless steel mounting clamps. |
