FEATURES:

Pre-treatment included

• Wall mount vessels (2) 10-BB
• Sediment cartridge FM-BB-10-1
• Activated carbon cartridge WCBCFF975

Reverse osmosis system, PUR-O-01A Series

• Stainless steel frame
• Stainless steel leg kit
• Automatic inlet valve
• Pre-filter housing and cartridge, 10"
• Procon pump (brass) with 1/2 HP motor
• Liquid filled pump pressure gauge (2-1/2")
• Stainless steel pressure vessels
• Needle valve for concentrate line
• Needle valve for recycle line
• Check valve for product water (stainless steel)
• Product pressure switch with Auto/Off
• Low-pressure shut-off with automatic restart
• Typical rejection rate of 98 %
• Recovery rate up to 75 %

Additional features included in PUR-O-1B Series

• Pre-filter pressure gauges
• Product water flow meter
• Reject water flow meter

Additional features included in PUR-O-1C Series

• Automatic fast flush for concentrate

Part NumberPermeate output GPD (25 C) Membranes size and number Dimensions(LxHxD)
PUR-O-01A-1501502 ½’’ x 14’’22’ x 32’’ x 12’’
PUR-O-01B-150
PUR-O-01C-150
PUR-O-01A-2502502 ½’’ x 21’’22’ x 32’’ x 12’’
PUR-O-01B-250
PUR-O-01C-250
PUR-O-01A-6006002 ½’’ x 40’’22’ x 52’’ x 12’’
PUR-O-01B-600
PUR-O-01C-600
PUR-O-01A-12001200(2)  2 ½’’ x 40’’22’ x 52’’ x 12’’
PUR-O-01B-1200
PUR-O-01C-1200






Part NumberModel
PUR-O-01-SPLeg kit
PUR-O-FLLevel float
PUR-O-165Atmospheric storage tank, 165 gallons, with level float and GRUNDFOS MQ3 pump
PUR-O-300Atmospheric storage tank, 300 gallons, with level float and GRUNDFOS MQ3 pump
PUR-O-500Atmospheric storage tank, 500 gallons, with level float and GRUNDFOS MQ3 pump
Model Item Quantity Unit Price Line Total
PUR-O-01A (150) - PUR-O-01 Series
$ 0.00
PUR-O-01B (150) - PUR-O-01 Series
$ 0.00
PUR-O-01C (150) - PUR-O-01 Series
$ 0.00
PUR-O-01A (250) - PUR-O-01 Series
$ 0.00
PUR-O-01B (250) - PUR-O-01 Series
$ 0.00
PUR-O-01C (250) - PUR-O-01 Series
$ 0.00
PUR-O-01A (600) - PUR-O-01 Series
$ 0.00
PUR-O-01B (600) - PUR-O-01 Series
$ 0.00
PUR-O-01C (600) - PUR-O-01 Series
$ 0.00
PUR-O-01A (1200) - PUR-O-01 Series
$ 0.00
PUR-O-01B (1200) - PUR-O-01 Series
$ 0.00
PUR-O-01C (1200) - PUR-O-01 Series
$ 0.00
Leg kit - PUR-O-01 Series
$ 0.00
Level Float - PUR-O-01 Series
$ 0.00
165 gallons Atmospheric storage tank - PUR-O-01 Series
$ 0.00
300 gallons Atmospheric storage tank - PUR-O-01 Series
$ 0.00
500 gallons Atmospheric storage tank - PUR-O-01 Series
$ 0.00
$ 0.00
