Standard features

• Powder coated steel frames
• Inlet solenoid valve
• Pre-filter
• 1/2 HP motor
• Brass pump
• Liquid filled pre-filter pressure gauge
• 2 1/2" liquid filled pump pressure gauge
• Product water & reject water flow meters
• High pressure, non-metallic membrane housings
• SS needle valves for concentrate and recycle lines
• Stainless steel product water check valve
• On / Off toggle switch
• Low-pressure shut-off with auto restart
• Feed water and product water TDS monitor
• High tank level input (dry contact)
• Pretreatment interlock input (dry contact)
• Pump start delay
• Inlet valve delay

Applications

• Whole house
• Ice makers
• Labs
• Beverages
• Coffee shops
• Restaurants

Specifications

• 3/4" NPTF Feed water connection
• 3/8" Tubing OD
• 2.4 GPM Maximum Feed water required
• 10 PSI Minimum Feed water pressure
• 2.4 GPM Maximum Drain required
• 120 VAC 60 Hz
• 8 Amps
• 1/2 Pump (H.P.)

Model Item Quantity Unit Price Line Total
Default Title - Reverse Osmosis R13 Series
$ 0.00
$ 0.00
