Underwater cables, SDI-12 adapter cable, data cable, USB adapter and turbidity standard for Solinst Eureka Manta+, Trimeter and EasyProbe water quality sondes. The underwater cable links the probe to a PC, the mantaMobile, a datalogger or a telemetry station; the SDI-12 adapter connects a MIB-equipped probe to third-party SDI-12 dataloggers.
- Underwater cables from 3 to 200 m with a marine connector at the probe; 3, 15 and 30 m listed, other lengths on request
- SDI-12 adapter cable plugs into the 9-pin end of the underwater cable and outputs SDI-12 to third-party dataloggers
- SDI-12 and MODBUS output need the Multi-Protocol Interface Board (MIB), built into Manta+ and Trimeter probes at manufacture
- Data cable for office work and calibration; connects to a Windows PC through the USB adapter
- USB adapter also takes an external 12 V supply when USB power is not enough (long cables, many sensors)
- Manta+ ships with the data cable and USB adapter; Trimeter and EasyProbe do not, and underwater cables are sold separately for every model
- 100 FNU turbidity calibration standard, 1 L, for the wipered Eureka turbidity sensor
Other underwater cable lengths up to 200 m, vented cables, the MODBUS adapter cable, cable reels, flow cells, copper-gauze anti-fouling guards, battery packs, backpacks, pipe kits and other calibration standards are quoted on request. Request a quote for pricing and availability.
Specifications
- Compatible Probes
- Solinst Eureka Manta+20, 25, 30, 35, 40, Manta F35, Trimeter and EasyProbe
- Underwater Cables
- 3 to 200 m; marine connector at the probe, 9-pin connector at the top for the mantaMobile, USB adapter, SDI-12 / MODBUS adapter cable or a datalogger
- Listed Cable Lengths
- 3 m (SO-402001), 15 m (SO-402004), 30 m (SO-402007); other lengths on request
- Vented Cables
- Included with probes that have a vented depth sensor
- SDI-12 Adapter Cable
- Connects to the 9-pin connector of the underwater cable; three bare wires to the SDI-12 master; tells the probe to answer in SDI-12 instead of RS-232
- SDI-12 / MODBUS Requirement
- Multi-Protocol Interface Board (MIB), built in at manufacture on Manta+ and Trimeter probes; works through an underwater cable only, not the data cable
- SDI-12 / MODBUS Supply
- +5 to 15 VDC
- Data Cable
- Short Manta+ cable for office use and calibration; talks to a PC through the USB adapter; no SDI-12 or MODBUS
- USB Adapter
- Connects a data cable or underwater cable to a USB port on a Windows PC; input for an external 12 V supply
- Standard With the Probe
- Manta+: data cable and USB adapter included. Trimeter and EasyProbe: not included. Underwater cables: sold separately
- Turbidity Standard
- 100 FNU, 1 L (FNU and NTU are interchangeable on the Eureka turbidity sensor)
- Warranty
- Solinst Eureka warranty terms
