Features

• Telescopic rod extends up to 6m
• Range of different sized sample collecting Chambers
• 316L stainless steel construction with PTFE clutch

Operation

1. Insert sampler into the product.
2. This action forces the sleeve upwards covering the sample hole and stopping powder from entering.
3. On pulling the sampler upwards, the sleeve moves down and the product can now enter the sampler.
4. Withdraw the sampler
5. Pull sleeve back to discharge powder

*Note - transport case also available

Part NumberModelLengthVolumeMaterial
SS-1035P-001Sample Chamber-1ml316L stainless steel
SS-1035P-002Sample Chamber-2ml316L stainless steel
SS-1035P-100Sample Chamber-100ml316L stainless steel
SS-1035P-150Sample Chamber-150ml316L stainless steel
SS-1035P-200Sample Chamber-200ml316L stainless steel
SS-5065A-1001Rod (Fixed Length)1000mm-Aluminum & Plastic
SS-5065A-1201Telescopic Rod1200mm-Aluminum & Plastic
SS-5065A-2501Telescopic Rod2500mm-Aluminum & Plastic
SS-5065A-2801Telescopic Rod2800mm-Aluminum & Plastic
SS-5065A-3001Telescopic Rod3000mm-Aluminum & Plastic
SS-5065A-4501Telescopic Rod4500mm-Aluminum & Plastic
SS-5065A-6001Telescopic Rod6000mm-Aluminum & Plastic
SS-5065S-1500Telescopic Rod1500mm-316L stainless steel & PTFE
SS-5065S-3000Telescopic Rod3000mm-316L stainless steel & PTFE
SS-5065S-4500Telescopic Rod4500 mm-316L stainless steel & PTFE
