Glacier UV LED Model GUV-4S

Name: Glacier UV LED Model GUV-4S
Brand: LUMINOR
SKU: LU-GUV-4S
Availability: OutOfStock

SKU: LU-GUV-4S

Brief Description:

Fully integrated LED based UV water treatment system with multi-state status LED

Model

Quantity:

- +

Add to Wishlist

Quantity must be 1 or more

View Quote

This fully integrated LED based UV water treatment system is available with a simple multi-state status indicator. This system is package with a 12 volt power supply and there is no need for a lamp change, as in traditional UV systems. The UVC LED's only turn “on” when needed based on an integral flow switch, and last for 5,000 hours of “on” mode operation.

The system incorporates integrated, real-time I/O monitoring for:

Temperature
• Prevents overheating of LED's
• Alarm alerts of over temperature conditions

LED Status
• Always know when UVC LED is on or off
• Alarm is signaled in event that the UVC KED fails

Part Number	LU-GUV-4S
Flow Rate (@ 10 mJ/cm² @ 95% UVT)	1.5 gpm
Flow Rate (@ 10 mJ/cm² @ 95% UVT)	5.6 lpm
Flow Rate (@ 16 mJ/cm² @ 95% UVT)	1.3 gpm
Flow Rate (@ 16 mJ/cm² @ 95% UVT)	4.9 lpm
Flow Rate (@ 30 mJ/cm² @ 95% UVT)	0.6 gpm
Flow Rate (@ 30 mJ/cm² @ 95% UVT)	2.4 lpm
Flow Rate (@ 40 mJ/cm² @ 95% UVT)	0.4 gpm
Flow Rate (@ 40 mJ/cm² @ 95% UVT)	1.3 lpm
UVT (%)	Recommended above 90%
Headloss at Max Flow	166 mBar (2.4 psi)
Max Pressure	6.9 bar (100 psi)
Max Ambient Temperature	50°C (122°F)
Operating Water Temperature	0-45°C (32-113°F)
Water Connections	3/8" OD Tube (fits John Guest® style quick connect fittings)
Input Voltage	12 VDC
Input Power	15 W
UV Intensity Monitoring	N/A
Electrical Connection	Standard 12VDC barrel connector, 2.1 x 5.5 mm
LED Status Monitoring	Yes
LED Life Monitoring	Yes
LED Life	5,000 hours
4-20 mA Output	N/A
Solenoid Output	N/A
Dry Contacts (Solenoid Ready)	N/A
IoT	N/A
Display	Dual color LED
Overall Dimensions (with mounting brackets)	241mm x 104mm x 107mm (9.5" x 4.1" x 4.2")
Shipping Weight	400g (14 oz)
