Features
• Constructed of 316 Stainless Steel
• No special tools or training required to service the pump
• Drop tube intake option allows for deeper sampling
• Compatible with geocontrol PRO and 300 psi & 500 psi BP Controllers

*Replacement PTFE bladders also available

Part NumberGT-1.66X36PGT-1.66X18PGT-850X18PGT-675X18P
Pump Housing316 Stainless Steel316 Stainless Steel316 Stainless Steel316 Stainless Steel
Pump Ends316 Stainless Steel316 Stainless Steel316 Stainless Steel316 Stainless Steel
Bladder MaterialVirgin PTFEVirgin PTFEVirgin PTFEVirgin PTFE
Outer Diameter1.66" O.D.1.66" O.D.0.850" O.D.0.675" O.D.
Length With Screen40" L19" L18 5⁄8" L18 3⁄4" L
Weight5.0 lbs3.0 lbs1.1 lbs0.83 lbs
Volume/Cycle11 oz. (310 ml)5 oz. (150 ml)0.9 oz. (29 ml)0.5 oz. (15 ml)
Min. Well Interior Diameter2" I.D.2" I.D.1" I.D.0.75" I.D.
Max. Operating Pressure100 psi (6.9 bar)100 psi (6.9 bar)100 psi (6.9 bar)100 psi (6.9 bar)
Min. Operating Pressure5 psi (0.3 bar) ash*5 psi (0.3 bar) ash*5 psi (0.3 bar) ash*5 psi (0.3 bar) ash*
Max. Smapling Depth200 ft (60 m)200 ft (60 m)200 ft (60 m)200 ft (60 m)
Replacement PE BladderGT-21150056-EGT-21150056-EGT-21150099-EGT-21150101

Tubing Required          Air





                                   Water (Discharge)

WA-1/4-LDPE-100
WA-1/4-HDPE-100



WA-3/8-LDPE-100
WA-3/8-HDPE-100

WA-1/4-LDPE-100
WA-1/4-HDPE-100



WA-3/8-LDPE-100
WA-3/8-HDPE-100

WA-1/4-LDPE-100
WA-1/4-HDPE-100



WA-1/4-LDPE-100
WA-1/4-HDPE-100

WA-1/4-LDPE-100
WA-1/4-HDPE-100



WA-1/4-LDPE-100
WA-1/4-HDPE-100

Model Item Quantity Unit Price Line Total
310 ml - volume/cycle - Portable Bladder Pumps
$ 0.00
150 ml - volume/cycle - Portable Bladder Pumps
$ 0.00
29 ml - volume/cycle - Portable Bladder Pumps
$ 0.00
15 ml - volume/cycle - Portable Bladder Pumps
$ 0.00
$ 0.00
