With Bar Code Recognition of Sample Vials

Features

• Measures Ammonia, Chlorine, COD, Nitrate, Nitrogen and Phosphorus
• Bar code reader detects the method and range automatically
• Three operation modes: Automatic, Semi-Automatic and Manual
• Bar coded pre-dosed reagent vials
• On-screen step-by-step tutorial
• Logs up to 200 samples
• Context sensitive help screen at a touch of a button
• Selection of languages
• USB connection
• Graphic LCD

HA-83224 Specifications

• Comes with Sample Vials (10), Vial Cleaning Cloths (4), Scissors & Instruction Manual
• Tungsten lamps with narrow-band interference filters
• Silicon photocells light detector
• Up to 200 samples Date Logging
• 230 V AC or 115 V AC power adapter
• 235 mm x 212 mm x 143 mm (9.2" x 8.34" x 5.62")
• 2.3 kg (5.1 lbs)

Part NumberMeasuresType of RangeRangeMethodQuantity
HA-94764A-25AmmoniaLR Range0.00 to 3.00 mg/LNessler25
HA-94764B-25AmmoniaHR Range0 to 100 mg/LNessler25
HA-93701-01ChlorineFree Range0.00 to 5.00 mg/LDPD100
HA-93711-01ChlorineTotal Range0.00 to 5.00 mg/LDPD100
HA-94754A-25Chemical Oxygen DemandLR Range0 to 150 mg/LDichromate, Mercuric Sulfate25
HA-94754B-25Chemical Oxygen DemandMR Range0 to 1500 mg/LDichromate, Mercuric Sulfate25
HA-94754C-25Chemical Oxygen DemandHR Range0 to 15000 mg/LDichromate, Mercuric Sulfate25
HA-94766-50Nitrate-0.0 to 30.0 mg/LChromotropic Acid50
HA-94767A-50NitrogenTotal LR Range0.0 to 25.0 mg/LChromotropic Acid50
HA-94767B-50NitrogenTotal HR Range10 to 150 mg/LChromotropic Acid50
HA-94758B-50PhosphorusAcid Hydrolyzable Range0.00 to 1.60 mg/LAscorbic Acid50
HA-94758A-50PhosphorusReactive Range0.00 to 1.60 mg/LAscorbic Acid50
HA-94763A-50PhosphorusReactive HR Range0.0 to 32.6 mg/LVanadomolybdophosphoric Acid50
HA-94758C-50PhosphorusTotal Range0.00 to 1.15 mg/LAscorbic Acid50
HA-94763B-50PhosphorusTotal HR Range0.0 to 32.6 mg/LVanadomolybdophosphoric Acid50
Model Item Quantity Unit Price Line Total
Photometer - HA-83224 Multiparameter Photometer
$ 0.00
Ammonia LR Range - HA-83224 Multiparameter Photometer
$ 0.00
Ammonia HR Range - HA-83224 Multiparameter Photometer
$ 0.00
Chlorine Free Range - HA-83224 Multiparameter Photometer
$ 0.00
Chlorine Total Range - HA-83224 Multiparameter Photometer
$ 0.00
Chemical Oxygen Demand LR Range - HA-83224 Multiparameter Photometer
$ 0.00
Chemical Oxygen Demand MR Range - HA-83224 Multiparameter Photometer
$ 0.00
Chemical Oxygen Demand HR Range - HA-83224 Multiparameter Photometer
$ 0.00
Nitrate Range - HA-83224 Multiparameter Photometer
$ 0.00
Nitrogen LR Range - HA-83224 Multiparameter Photometer
$ 0.00
Nitrogen HR Range - HA-83224 Multiparameter Photometer
$ 0.00
Phosphorus Acid Hydrolyzable Range - HA-83224 Multiparameter Photometer
$ 0.00
Phosphorus Reactive Range - HA-83224 Multiparameter Photometer
$ 0.00
Phosphorus Reactive HR Range - HA-83224 Multiparameter Photometer
$ 0.00
Phosphorus Total Range - HA-83224 Multiparameter Photometer
$ 0.00
Phosphorus Total HR Range - HA-83224 Multiparameter Photometer
$ 0.00
$ 0.00
